3D Reverse Engineering and 3D Inspection Services
3D Reverse Engineering Services
Reverse Engineering is the process of measuring existing physical parts that originally designed for traditional manufacturing processes using non-contact 3D scanners. Reverse Engineering requires when a company wants to make improvements to an existing design (for instance legacy parts) and when they have inadequate design documentation such as 3D CAD and 2D drawings for modern manufacturing process. Vital 3D is able to perform reverse engineering services using 3D scanners to CAD redesign a wide range of parts for further engineering process. Reverse engineering using 3D scan data is very efficient and effective process to generate a CAD model from a physical object.
If you require change manufacturing design, changes in the product design or broken tool/fixtures, please contact us.
3D Inspection Services
We offer 3D dimensional analysis and quality control inspection service in accordance with ISO 9001 quality management system, ISO9001 provides the framework for a quality management system that helps businesses identify risks and opportunities to improve manufacturing process,
Prototype parts are typically produced in small quantities, and they are measured against a blueprint or compared with a CAD file to make sure they were accurately produced.
Prototype inspection
Prototype parts are typically produced in small quantities, and they are measured against a blueprint or compared with a CAD file to make sure they were accurately produced.
Part-to-CAD Inspection
The part-to-CAD 3D deviation can be analysed with colour maps and user-defined comparison points based on all the measurements taken by the 3D scanner. Using the high-density data provided by the scanner and report complete inspection of the part on all its surfaces.
First Article Inspection (FAI) of Manufactured Parts
The inspection of the first manufactured parts is essential for the development of any manufacturing process. First Article Inspections gives manufacturers and customers confidence in production process verification requirements. Also highlights the information that needs to be rectify and opportunities to improve the process if any non-conformances are found. First Article Inspection Report (FAIR) mitigate the risk and verify the customer’s specification and purchase order in accordance with AS9102.
Contact us today for all your Inspection Service requirements.
