Creatbot D600 Pro

£12,999.00

Quantity

Affordable and Reliable Large 3D printer

The CreatBot D600 Pro was created to make industrial 3D printing of large-scale objects and prototype as easy as possible. It is embedded with many advanced technology for Ultra big, impressive, prints. It will be your best choice with no doubt, if you are looking for an industrial large scale 3D printer for prototype and engineering-grade materials.

Affordable price plus a build size 600*600*600mm, make it the best choice to your business. Trusted by 2000+ professional clients.

Features

600*600*600mm
420°C+120°C+70°C
High resolution & speed
Camera control technology
Reliable 24/7
Fully enclosed

Nozzle Temperature Up To 420 ℃

D600 and D600 Pro equipped with the 4th generation 1.75mm dual extruders and hotends. The left extruder equipped with 260°C hotend, It is able to print with PLA, ABS, PC, Nylon, Carbon fiber, Flexible, etc. The right extruder 420°C hotend is made of martensite steel, which is able to print high performance materials. The dual hotend is replaceable, which provide more possibility on your application.

High Precision

We exclusively research and develop the extruder feeding system support high-speed printing, and accuracy can reach high to 0.05mm, it allows to extrude filament steady without block.

Outage Restore & Filament Detection

The printer will automatically memorize the current position and save print data. Lower the platform and withdraw filament when power off suddenly. It will continue to print from the last stopped point after power on. No trace!

The printer will avoid invalid printing by stoping print and warning when filament runs out.

Linear rail and Servo motors

When it reachs to 600mm+ length, small rail have big deflection. The D600 Pro accurate linear rail structure is very thick and strong. It won’t deform or loss precision after print head million times shock.

With servo motors, timeliness, fast response, no inertia, no delay. closed-loop control of position overcome the problem of lossing step. heat and noise are significantly reduced. It gives print model ultra high performance with high speed.

Hot Chamber + Filament Dry Room

70°C hot chamber ensures print quality for high performance materials. The fully enclosed chamber can block all external interference. Also this frame can reduce noises, at the same time to provide constant temperature, so that the model won't deform.

The filament dry room provides chamber temperatures of 45°C and 65°C to dry big roll filament like PLA, nylon, PC, ABS and other materials with water absorption.

Auto Leveling Platform

Use of 49 points through the high precision servo probe to save the level of platform flatness data at the initial, through the Z axis intelligent compensation table height in the printing process to achieve fully automatic leveling.

HEPA Air Filter

The air filter system can adsorb impurities and gases that generated by printing special filament like ABS, Nylon, PC, more safe and environmental protection which is more suitable for house, school, office space.

Technical Specification

Printing

Print Technology	Fused Deposition Modeling（FDM）
Build Volume	Single Extrusion: 600600600 mm Dual Extrusion: 540600600 mm
Number of Nozzles	Double
Layer Resolution	0.05 mm
Filament Diameter	1.75 mm
Filament Compatibility	PLA, ABS, Carbon Fiber, Wood, Nylon, PC, PETG, HIPS, PP, Flexible, TPU, PVA, etc.
Nozzle Diameter	0.4mm (0.3 0.5 0.6 0.8 1.0mm)
Print File Type	STL, OBJ, AMF, Gcode

Electrical

Power Requirements	200V-240V / 50-60Hz ( D600 / D600 Pro )
Screen	4.3'' Touch Screen with Multi-language
Rated Power	D600: 1500W, D600 Pro: 4900W
Storage Media	USB Disk
Connectivity	USB

Mechanical

Construction	Power-Coated Steel, Aluminum Casting for Motion Components, POM
Build Plate	Aviation aluminum plate
Build Plate Leveling	Factory Leveled, Adjust Manually Automatic D600 Pro
Extruder	Directly Drive
Stepper Motors	1.8° Step Angle with 1/16 Micro-stepping
X Y Positioning Precision	5.08 μm
Z Positioning Precision	1.25 μm

Temperature

Ambient Operating Temperature	15 ℃~32 ℃
Max. Nozzle Temperature	420 ℃
Max. Bed Temperature	100 ℃
Max. Chamber Temperature	70 ℃ D600 Pro
Filaments Drying Temperature	45 ℃/65 ℃ D600 Pro

Software

Software	CreatWare, Simplify 3D, Cura, Slic3r, etc
Supported File Types	STL,OBJ,AMF
Operating Systems	Win7/8/10, macOS

Special Function

Outage Restored	Save data when power is off
Filament Detection	Pause printing when filament run out
Automatic Shut-down	Turn off the power automatically when printing is complete
