Formfutura CarbonFil 1.75mm | 500g

£37.99

Colour

Quantity

Item number: 8718924473092

Key Features:

Reinforced with 15% ultra-lightweight and relatively long carbon fibre stringers
Extremely stiff
Two times as stiff as HDglass (or even more compared to other PETG-based filaments)
Great impact resistance
10% more impact resistant than HDglass (or even more compared to other PETG-based filaments)
Very easy to print
Nearly warp-free, improved thermal stability, nearly perfect first layer and inter-layer adhesion
Good first layer adhesion to a heated glass print bed and many other surfaces
Heat deflection temperature of ± 85° C
Great dimensional stability

Application:

Industrial Components and Tooling

Functional Parts
Equipment and Machinery
End-use parts
Prototypes
Decorations
Jewellery

Description

CarbonFil is a 15% carbon fiber reinforced PETG based 3D printer filament that is extremely stiff. CarbonFil 3D prints 3D prints with a high dimensional accuracy and virtually no warping.

Specification


Diameter	1.75mm
Tolerance	± 0.05mm
Roundness	≥ 95%
Net weight	500g

Recommendation

Temperature

Print temp: 230 – 265° C

Heat bed: 0 – 85° C

Printing Speed

Printing Speed: Medium

Fan

Fan speed: 20 - 50%

Surface

EasyFix Nr. I, Magigoo

Closed Chamber

Nozzle Diameter

≥ 0.15mm

Note

Abrasiveness

Please be aware that CarbonFil filaments contain a relatively high concentration of extremely hard carbon fibres, which have an abrasive nature. In general these carbon fibres will accelerate the nozzle-wear of brass nozzles, much faster than unfilled filaments. We recommend to use nozzles from stainless steel or other hardened alloys.

Nozzle cleaning

When printing with filled/composite filaments it is recommended to clean your nozzle immediately after printing by feeding 15-20cm PLA filament through your nozzle. This will make sure that any potential fillers are flown out of your nozzle. It is even better to use glow in the dark PLA as the extremely hard phosphorous particles are much more likely to scrape out residual waste from your nozzle.
